Accessories and spares

DPVs coupling set – wide platform

Double the power

A dedicated DPV coupling platform allows connecting two Seacraft scooters together. The primary reasons to combine them are:

more power – two propellers double the thrust and provide a very powerful towing system
highly increased maximum speed (even 120m/min)
significantly increased driving range
simultaneous control and monitoring over two scooters

Transport extended capability

Dedicated coupling sets with wide platforms allow tp connection of two separate DPVs to not only gain more power but allow to use of the extended capability of a wide platform for cargo and equipment transport, especially for long cave dive explorations.

almost limitless options to transport additional tanks, batteries, hard and soft dry containers, rebreathers, big photo/video rigs, and other equipment
construction of the platform provides multi-options for attaching external equipment attached points on front and back of the platform frame in example large camera dimensions or navigation systems
fewer items needed to be attached/towed by the diver – especially backup scooter, as scooters forming the platform can be momentarily disconnected
due to positive lift in the platform buoyancy tubes, (+290g each tube) the whole set-up can be simply trimmed in the water

Quick coupling fast and reliable

A patented connection system allows to combine the DPVs in a moment – simply by pushing them together. Disconnecting is easy, even when using thick cold-water gloves. The platform itself is a separate element, simplifying activities such as trimming and transporting additional equipment attached to it.

The coupling set with the wide platform is dedicated to Seacraft Future and Ghost DPVs and other scooters with 160 and 208 mm diameter dedicated transport brackets.

Coupling platform A closer look

Specifications

The coupling platform is attached to the DPVs’ transport brackets, with attached patented quick coupling connectors. Depending on the used brackets, their parameters will vary.

Dimensions

Scooters coupling set - wide platform

Width:

Scooters coupling set - wide platform29 cm

Lenght:

Scooters coupling set - wide platform45,5 cm

Height:

Scooters coupling set - wide platform8,3 cm

Housing diameter:

Scooters coupling set - wide platformeach buayancy tube diameter - 50mm

Weight:

Scooters coupling set - wide platform1,10kg

Other

Scooters coupling set - wide platform

Maximum depth:

Scooters coupling set - wide platform300m

Displacement:

Scooters coupling set - wide platformPlatform buoyancy, with emply floats = +1,6kg in fresh water

Material:

Scooters coupling set - wide platformDelrin and stainless steel

Internal volume (fillable with water) of each float = 0,5l

DPVs 160mm coupling set with wide platformSET INCLUDE

Cat. No.

Part name

Quantity

Cat. No.TU1000

Part name

Coupling platform - wide

Quantity1pc

Cat. No.TU1158

Part name

Coupling connector's set - front and rear (POM)

Quantity4pcs

Cat. No.F1057

Part name

Multipurpose transport bracket ϕ160 mm

Quantity4pcs

DPVs 208mm coupling set with wide platformSET INCLUDE

Cat. No.

Part name

Quantity

Cat. No.TU1000

Part name

Coupling platform - wide

Quantity1pc

Cat. No.TU1158

Part name

Coupling connector's set - front and rear (POM)

Quantity6pcs

Cat. No.G1057

Part name

Aluminium transport bracket ϕ208 mm

Quantity4pcs

IN ACTION

PRICING

DPVs ϕ160mm coupling set with wide platformTF1800

1860 EUR

DPVs ϕ208mm coupling set with wide platformTG1800

2620 EUR

Coupling platform - wideTU1000

1660 EUR

Coupling connector's set - front and rear (POM) - 1 pieceTU1158

90 EUR

Multipurpose transport bracket ϕ160 mmF1057

60 EUR

Aluminium transport bracket ϕ208 mmG1057

260 EUR

Pricing

Pricing does not include taxes (VAT) or shipping and packaging. Pricing is valid for the EU countries, and presented in Euro currency. For other countries please contact directly our Dealers or Distributors. Please note that it is presented as indication only.

Ordering

To get our products, see where is the nearest dealer located.
